  • iC-GD


    Universal IO-Interface.

    Features

    Two channels, each configurable as input or output.
    Low-side and high-side switches with up to 500mA per channel, current limitation, current measurement, status messages, cable break detection, freewheeling diode, reverse polarity protection, optional parallel connection of both channels.
    Output of ±10V or 0/4…20mA with 14-bit resolution.
    Measurement of ±10V, ±1V, ±100mV, ±10mV, ±20mA or 4…20mA with 14-bit resolution.
    Input for Pt 100, Pt 1000 temperature sensors.
    Multi-function 32-bit counter.
    Digital output with pulse-width modulation option.
    Internal temperature measurement with 1 K resolution.
    SPI interface.
    Calibration and configuration by external EEPROM via serial interface.
    Error message at over-temperature, overload and under-voltage.
    Shutdown of the outputs in case of error.
    Operating ambient temperature -20…85°C.

    Datasheet

    iC-GD Datasheet

    Manufacturer: iCHaus GmbH

    Read more

  • iC-PNH2628


    ∅26.0mm, 128 CPR Phased Array Nonius Encoder.


    Features

    Compact, high resolution absolute encoder ICs for up to 24 bit singleturn resolution (with nonius interpolation).
    For code discs of ∅26 mm.
    128 CPR (2x 64/63/56 CPR).
    11.0mm optical radius.
    Monolithic 3-channel HD Phased Array with excellent signal matching.
    Moderate track pitch for reduced cross talk.
    Ultra low dark currents for operation up to high temperature.
    Low noise amplifiers with high transimpedance gain.
    Enhanced EMI tolerance by low impedance differential, short-circuit-proof, analog sine/cosine outputs.
    Embedded sector detection by 2 digital tracks (2-bit Gray code).
    Low power consumption from single 4.1 to 5.5V supply.
    Operational temperature range of -40°C to +125°C.
    Space saving optoQFN package (RoHS compliant).
    Evaluation kits with LED and code disc available for sampling.


    Datasheets

    iC-PNH26xx series Datasheet
    Code Disc PNH6S 26-128 Datasheet
    Demo Board iC-PNH series IC273 Datasheet

    Manufacturer: iCHaus GmbH

    Read more

  • iC-PNH2612


    ∅26.0mm, 512 CPR Phased Array Nonius Encoder.


    Features

    Compact, high resolution absolute encoder ICs for up to 24 bit singleturn resolution (with nonius interpolation).
    For code discs of ∅26 mm.
    512 CPR (2x 256/255/240 CPR).
    11.0mm optical radius.
    Monolithic 3-channel HD Phased Array with excellent signal matching.
    Moderate track pitch for reduced cross talk.
    Ultra low dark currents for operation up to high temperature.
    Low noise amplifiers with high transimpedance gain.
    Enhanced EMI tolerance by low impedance differential, short-circuit-proof, analog sine/cosine outputs.
    Embedded sector detection by 2 digital tracks (2-bit Gray code).
    Low power consumption from single 4.1 to 5.5V supply.
    Operational temperature range of -40°C to +125°C.
    Space saving optoQFN package (RoHS compliant).
    Evaluation kits with LED and code disc available for sampling.


    Datasheets

    iC-PNH26xx series Datasheet
    Code Disc PNH3S 26-512 Datasheet
    Demo Board iC-PNH series IC273 Datasheet

    Manufacturer: iCHaus GmbH

    Read more

  • iC-PNH2624


    ∅26.0mm, 1024 CPR Phased Array Nonius Encoder.


    Features

    Compact, high resolution absolute encoder ICs for up to 24 bit singleturn resolution (with nonius interpolation).
    For code discs of ∅26 mm.
    1024 CPR (2x 512/511/480 CPR).
    11.0mm optical radius.
    Monolithic 3-channel HD Phased Array with excellent signal matching.
    Moderate track pitch for reduced cross talk.
    Ultra low dark currents for operation up to high temperature.
    Low noise amplifiers with high transimpedance gain.
    Enhanced EMI tolerance by low impedance differential, short-circuit-proof, analog sine/cosine outputs.
    Embedded sector detection by 2 digital tracks (2-bit Gray code).
    Low power consumption from single 4.1 to 5.5V supply.
    Operational temperature range of -40°C to +125°C.
    Space saving optoQFN package (RoHS compliant).
    Evaluation kits with LED and code disc available for sampling.


    Datasheets

    iC-PNH26xx series Datasheet
    Code Disc PNH5S 26-1024 Datasheet
    Demo Board iC-PNH series IC273 Datasheet

    Manufacturer: iCHaus GmbH

    Read more

  • iC-PNH3312


    ∅33.2mm, 512 CPR Phased Array Nonius Encoder.


    Features

    Compact, high resolution absolute encoder ICs for up to 24 bit singleturn resolution (with nonius interpolation).
    For code discs of ∅33.2mm.
    512 CPR (2x 256/255/240 CPR).
    14.5mm optical radius.
    Monolithic 3-channel HD Phased Array with excellent signal matching.
    Moderate track pitch for reduced cross talk.
    Ultra low dark currents for operation up to high temperature.
    Low noise amplifiers with high transimpedance gain.
    Enhanced EMI tolerance by low impedance differential, short-circuit-proof, analog sine/cosine outputs.
    Embedded sector detection by 2 digital tracks (2-bit Gray code).
    Low power consumption from single 4.1 to 5.5V supply.
    Operational temperature range of -40°C to +125°C.
    Space saving optoQFN package (RoHS compliant).
    Evaluation kits with LED and code disc available for sampling.


    Datasheets

    iC-PNH26xx series Datasheet
    Code Disc PNH2S 33-512 Datasheet
    Demo Board iC-PNH series IC273 Datasheet

    Manufacturer: iCHaus GmbH

    Read more

  • iC-PNH3348


    EncoderBlue® Phased Array Nonius Encoder.


    Features

    Compact, high resolution absolute encoder IC for up to 24 bit singleturn resolution (with nonius interpolation).
    For code disc of ∅33mm.
    2048 CPR (2x 1023/1024/992 CPR).
    Monolithic 3-channel HD Phased Array with excellent signal matching.
    Moderate track pitch for reduced cross talk.
    Ultra low dark currents for operation up to high temperature.
    Low noise amplifiers with high transimpedance gain.
    Enhanced EMI tolerance by low impedance differential, short-circuit-proof, analog sine/cosine outputs.
    Embedded sector detection by 2 digital tracks (2-bit Gray code).
    Low power consumption from single 4.1 to 5.5V supply.
    Operational temperature range of -40°C to +110°C.
    Space saving optoQFN package (RoHS compliant).
    Evaluation kit with LED and code disc available for sampling.


    Datasheets

    iC-PNH3348 Datasheet
    Code Disc PNH1S 33-2048 Datasheet
    Demo Board EncoderBlue IC273 Datasheet

    Manufacturer: iCHaus GmbH

    Read more

  • iC-PNH3948


    ∅39.0mm, 2048 CPR Phased Array Nonius Encoder.


    Features

    Compact, high resolution absolute encoder ICs for up to 24 bit singleturn resolution (with nonius interpolation).
    For code discs of ∅39.0mm.
    2048 CPR (2x 1023/1024/992 CPR).
    17.5mm optical radius.
    Monolithic 3-channel HD Phased Array with excellent signal matching.
    Moderate track pitch for reduced cross talk.
    Ultra low dark currents for operation up to high temperature.
    Low noise amplifiers with high transimpedance gain.
    Enhanced EMI tolerance by low impedance differential, short-circuit-proof, analog sine/cosine outputs.
    Embedded sector detection by 2 digital tracks (2-bit Gray code).
    Low power consumption from single 4.1 to 5.5V supply.
    Operational temperature range of -40°C to +125°C.
    Space saving optoQFN package (RoHS compliant).
    Evaluation kits with LED and code disc available for sampling.


    Datasheets

    iC-PNH26xx series Datasheet
    Code Disc PNH4RS 39-2048 Datasheet
    Demo Board iC-PNH series IC273 Datasheet

    Manufacturer: iCHaus GmbH

    Read more

  • iC-PR0464

    EncoderBlue® Reflective Optical Encoders (26mm).

    Features

    Lensless, reflective opto-encoder iCs, compact, high-resolution, incremental.
    Suitable reflective code discs of ∅4mm and linear scales (iC-PR256) available.
    Monolithic HD Phased Array with excellent signal matching.
    Integrated blue LED with power control, EncoderBlue®.
    Low-noise signal amplifiers with high EMI tolerance.
    Pin-selectable modes of operation:
    Digital A/B/Z (x1, x2, x4, x8, x16 interpolated), analog COS/SIN with analog or digital Z.
    Pin-selectable index gating:
    Ungated (1 T), B-gated (0.5 T), AB-gated (0.25 T).
    Pin-selectable minimal edge distance: 80 ns, 1 μs, 10 μs.
    Complementary quadrature outputs PA, NA,PB and NB.
    Complementary index outputs PZ and NZ.
    Analog signal output for ease of alignment and resolution enhancement by external interpolation.
    Operating temperature range of -40 °C to +105 °C.
    Compact and lensless optoQFN mold package.
    iC-PR0464 Encoder Ø 4 mm / 64 CPR (Code Disk PR06PS available).
    Evaluation kits on request.

    Datasheets

    iC-PR4307 Datasheet
    Demo Board PRM Datasheet

    Manufacturer: iCHaus GmbH

    Read more

  • iC-PR1456

    EncoderBlue® Reflective Optical Encoders (26mm).

    Features

    Lensless, reflective opto-encoder iCs, compact, high-resolution, incremental.
    Suitable reflective code discs of ∅14mm and linear scales (iC-PR256) available.
    Monolithic HD Phased Array with excellent signal matching.
    Integrated blue LED with power control, EncoderBlue®.
    Low-noise signal amplifiers with high EMI tolerance.
    Pin-selectable modes of operation:
    Digital A/B/Z (x1, x2, x4, x8, x16 interpolated), analog COS/SIN with analog or digital Z.
    Pin-selectable index gating:
    Ungated (1 T), B-gated (0.5 T), AB-gated (0.25 T).
    Pin-selectable minimal edge distance: 80 ns, 1 μs, 10 μs.
    Complementary quadrature outputs PA, NA,PB and NB.
    Complementary index outputs PZ and NZ.
    Analog signal output for ease of alignment and resolution enhancement by external interpolation.
    Operating temperature range of -40 °C to +105 °C.
    Compact and lensless optoQFN mold package.
    iC-PR1456 Encoder Ø 14 mm / 250, 256 CPR (Code Disk PR09PS, PR08PS available).
    Evaluation kits on request.

    Datasheets

    iC-PR4307 Datasheet
    Demo Board PRM Datasheet

    Manufacturer: iCHaus GmbH

    Read more

  • iC-PR26xx

    EncoderBlue® Reflective Optical Encoders (26mm).

    Features

    Lensless, reflective opto-encoder iCs, compact, high-resolution, incremental.
    Suitable reflective code discs of ∅26mm and linear scales (iC-PR256) available.
    Monolithic HD Phased Array with excellent signal matching.
    Integrated blue LED with power control, EncoderBlue®.
    Low-noise signal amplifiers with high EMI tolerance.
    Pin-selectable modes of operation:
    Digital A/B/Z (x1, x2, x4, x8, x16 interpolated), analog COS/SIN with analog or digital Z.
    Pin-selectable index gating:
    Ungated (1 T), B-gated (0.5 T), AB-gated (0.25 T).
    Pin-selectable minimal edge distance: 80 ns, 1 μs, 10 μs.
    Complementary quadrature outputs PA, NA,PB and NB.
    Complementary index outputs PZ and NZ.
    Analog signal output for ease of alignment and resolution enhancement by external interpolation.
    Operating temperature range of -40 °C to +105 °C.
    Compact and lensless optoQFN mold package.
    iC-PR2604 Encoder Ø 26 mm / 360 CPR (Code Disk PR04PS available).
    iC-PN2656 Encoder Ø 26 mm / 250, 256 PPR (Eval Kit PR10PS/PR05PS available).
    Evaluation kits on request.

    Datasheets

    iC-PR4307 Datasheet
    Demo Board PRM Datasheet

    Manufacturer: iCHaus GmbH

    Read more

  • iC-PR4307

    EncoderBlue® Reflective Optical Encoders (43mm).

    Features

    Lensless, reflective opto-encoder iCs, compact, high-resolution, incremental.
    Suitable reflective code discs of ∅43mm and linear scales (iC-PR256) available.
    Monolithic HD Phased Array with excellent signal matching.
    Integrated blue LED with power control, EncoderBlue®.
    Low-noise signal amplifiers with high EMI tolerance.
    Pin-selectable modes of operation:
    Digital A/B/Z (x1, x2, x4, x8, x16 interpolated), analog COS/SIN with analog or digital Z.
    Pin-selectable index gating:
    Ungated (1 T), B-gated (0.5 T), AB-gated (0.25 T).
    Pin-selectable minimal edge distance: 80 ns, 1 μs, 10 μs.
    Complementary quadrature outputs PA, NA,PB and NB.
    Complementary index outputs PZ and NZ.
    Analog signal output for ease of alignment and resolution enhancement by external interpolation.
    Operating temperature range of -40 °C to +105 °C.
    Compact and lensless optoQFN mold package.
    Evaluation kits on request.
    Code Disc PR08PS on request.

    Datasheets

    iC-PR4307 Datasheet
    Demo Board PRM Datasheet

    Manufacturer: iCHaus GmbH

    Read more

  • iC-PT26xx

    Features

    Compact, high resolution incremental encoder ICs with up to 2500 CPR (native) and 5,000 CPR (interpolated).
    For code discs of Ø 26mm and Ø 33mm.
    Excellent signal matching.
    Moderate track pitch for relaxed assembly tolerances.
    Low-noise signal amplifiers with high EMI tolerance.
    Pin-selectable operating modes: analog, digital, and x2 interpolated.
    Pin-selectable index gating: un-gated (1T), B-gated (0.5T), AB-gated (0.25T).
    Complementary quadrature outputs to 800 kHz: A, B, Z and NA, NB, NZ.
    Commutation signal outputs: U, V, W.
    Short-circuit-proof, current-limited, +/- 4mA push-pull.
    Analog signal output for ease of alignment and resolution enhancement by external interpolation.
    LED power control with 40mA high-side driver.
    Low power consumption from single 3.5 V to 5.5 V supply.
    Operational temperature range of -40 to +120°C.

    iC-PT2610 Encoder Ø 26 mm / 1000 PPR.
    iC-PT2613 Encoder Ø 26 mm / 1250 PPR.

    Evaluation kits with LED and code disc available.


    Datasheets

    iC-PT26xx Series Datasheet
    Code Disc PT26xx Series Datasheet
    Demo Board LT2M Datasheet

    Manufacturer: iCHaus GmbH

    Read more

  • iC-PT33xx

    Features

    Compact, high resolution incremental encoder ICs with up to 2500 CPR (native) and 5,000 CPR (interpolated).
    For code discs of Ø 26mm and Ø 33mm.
    Excellent signal matching.
    Moderate track pitch for relaxed assembly tolerances.
    Low-noise signal amplifiers with high EMI tolerance.
    Pin-selectable operating modes: analog, digital, and x2 interpolated.
    Pin-selectable index gating: un-gated (1T), B-gated (0.5T), AB-gated (0.25T).
    Complementary quadrature outputs to 800 kHz: A, B, Z and NA, NB, NZ.
    Commutation signal outputs: U, V, W.
    Short-circuit-proof, current-limited, +/- 4mA push-pull.
    Analog signal output for ease of alignment and resolution enhancement by external interpolation.
    LED power control with 40mA high-side driver.
    Low power consumption from single 3.5 V to 5.5 V supply.
    Operational temperature range of -40 to +120°C.

    iC-PT3310 Encoder Ø 33 mm / 1000 PPR.
    iC-PT3324 Encoder Ø 33 mm / 1024 PPR.
    iC-PT3313 Encoder Ø 33 mm / 1250 PPR.
    iC-PT3320 Encoder Ø 33 mm / 2000 PPR.
    iC-PT3348 Encoder Ø 33 mm / 2048 PPR.
    iC-PT3325 Encoder Ø 33 mm / 2500 PPR.

    Evaluation kits with LED and code disc available.


    Datasheets

    iC-PT33xx Series Datasheet
    Code Disc PT33xx Series Datasheet
    Demo Board LT2M Datasheet

    Manufacturer: iCHaus GmbH

    Read more

  • iC-TW28

    10-Bit Sin/Cos Interpolator with Auto-Calibration.

    Features

    Differential PGA inputs for sine, cosine, and index.
    700 kHz input frequency at full resolution.
    Automatic compensation of amplitude, offset, and phase errors.
    Low latency (typ. 1.5 μs).
    Differential RS422 line driver outputs for ABZ or UVW.
    Simultaneous single-ended outputs for ABZ and UVW.
    Digital filtering for ultra-low output jitter.
    Complete status and fault monitoring capabilities.
    Configured by pins or SPI.
    In-field re-configuration via Encoder Link interface.
    Easy to use with built-in line driver, EEPROM, and oscillator.
    Push-button automatic calibration for fast commissioning.
    LED intensity control by PWM output.
    10-bit angle data and 14-bit multi-cycle counter available to SPI.
    Capture register for coded reference marks and touch-probe applications.
    Space-saving 5 x 5mm QFN package.
    Single 3.3 V supply.

    Datasheets

    iC-TW28 Datasheet
    Demo Board TW28 1D Datasheet

    Manufacturer: iCHaus GmbH

    Read more

  • iC-PVL

    Linear/Off-Axis Battery-Buffered Hall Multiturn Encoder.

    Features

    Integrated Hall sensors with automatic gain and offset control.
    For magnetic scales of 1.0 up to 5.0mm pole width.
    Current consumption of only 2µA to 30µA in typ. applications.
    Tracking speed of up to 24m/s (1.5 mm poles) or 15,000rpm (32 pole pairs).
    Configurable multiturn counting up to 40 bits.
    Adjustable period count per revolution:
    FlexCount® logic for 1 to 256 pole pairs.
    Serial, parallel and incremental singleturn operating modes.
    SSI multiturn data output with error, warning, parity, and synchronisation bits.
    Multiturn preset by pin or command.
    I²C master function for initial boot-up from EEPROM.
    I²C slave function for controller operation.
    Supply voltage of 3.0V to 5.5V.
    Automatic low-power operation on backup battery.
    Overspeed, battery and RAM (CRC) monitoring.
    Space-saving 16-pin QFN package.

    Datasheets

    iC-PVL Datasheet
    Demo Board PVL1M Datasheet

    Manufacturer: iCHaus GmbH

    Read more

  • QL68I6Sx

    Feature

    QSI Red Laser Diode
    Wavelength: 683nm (typ.)
    Output Power: 30mW
    Package: TO18 (RoHS compliant)
    Built-in Monitor Photodiode


    Applications

    Industrial Sensors
    Laser Module


    Driver ICs

    This diode is best driven using the following IC Haus driver:
    iC-WKN
    iC-WKM
    iC-WKP
    iC-NZN
    iC-NZP
    iC-HK
    iC-HB


    Pin options

    This diode is available in the following pin types:
    QL68I6SA – N-type
    QL68I6SB – M-type
    QL68I6SC – P-type

    Read more

  • PLT5-510-B3

    Feature

    OSRAM Green Laser Diode
    Wavelength: 520-530nm (typ.)
    Output Power: 10mW
    Package: TO56 (RoHS compliant)

    Applications

    Laser Projection
    Biomedical Applications
    Holography
    Metrology

    Driver ICs

    This diode is best driven using the following IC Haus driver:
    iC-NZ
    iC-NZN
    iC-HK
    iC-HB

    Downloads

    Datasheet
    Read more

  • PLT5-510-B2

    Feature

    OSRAM Green Laser Diode
    Wavelength: 515-520nm (typ.)
    Output Power: 10mW
    Package: TO56 (RoHS compliant)

    Applications

    Laser Projection
    Biomedical Applications
    Holography
    Metrology

    Driver ICs

    This diode is best driven using the following IC Haus driver:
    iC-NZ
    iC-NZN
    iC-HK
    iC-HB

    Downloads

    Datasheet
    Read more

  • SFM-520-30-PT-HHL

    Feature

    Green Laser Fiber Module
    Wavelength: 520nm (typ.)
    Output Power: 30mW
    Package: HHL Pig-Tailed Fiber Couple with TEC
    Supplied Diode: PL-520


    Applications

    Medical Use
    Industrial Use

    Read more

  • NUBM05

    Feature

    Blue Laser Module (Diode Bank)
    Wavelength: 455nm (typ.)
    Output Power: 30mW
    Package: 8 LD Bank (RoHS compliant)
    No Outgas
    High Heat Dissipation
    Safety Structure to Stop Removal of LD

    Read more
