Triple 155 MHz Laser Switch with LVDS inputs

iC-HB

Triple 155 MHz Laser Switch with LVDS inputs.

Features

Laser switch for frequencies from CW up to 155MHz.
Spike-free switching of the laser currents.
Three channels with independent current control at pins Clx.
Operates as a voltage-controller current sink.
LVDS ⁄ TTL switching inputs with TTL monitor outputs.
Pulsed operation with up to 300mA per channel.
CW operation with up to 65mA per channel.
Laser current monitor output.
Thermal shutdown with open drain error output.
Protective ESD circuitry.

Datasheets

iC-HB Datasheet

Manufacturer: iCHaus GmbH

SKU: Triple 155 MHz Laser Switch with LVDS inputs Category: Tags: ,

Product Description

Applications

Laser printers
Data transmission
Laser scanning devices

Packages

QFN24

iC-HB package

Additional Information

Type

Laser Driver
Supply Current

mA
Laser Speed

Pulsed
Control Type

Open Loop
LD Pinout

E, G, H, M, N, P
