iC-MHA

Angular Hall Encoder with SIN/COS outputs.

Features

Sine ⁄ cosine differential outputs.
Automatic gain control for 1Vpp differential signal amplitude.
Operating speed from DC to 20 000 rpm.
Loss-of-magnet detection and error messaging.
Differential sine and cosine output signals.
Magnetic rotation speed up to 20,000 rpm.
Low output offset supporting 10bit interpolation accuracy.
Reasonable alignment tolerance.
Automatic gain control for 0.8 to 1.2Vpp output signal.
Loss of magnet detection and error message indication.
Extended temperature range of -40 to +125°C.

Datasheets


Manufacturer: iCHaus GmbH

SKU: Angular Hall Encoder with SIN/COS outputs Category: Tags: ,

Description

Applications

Resolver replacement
Contactless rotary sensor ⁄ potentiometer
Absolute and incremental rotary encoders
Motor feedback

Packages

QFN28
QFN28 Package

Additional information

Type

Encoder – Magnetic
