iC-NZ
Fail-Safe Laser Diode Driver, CW and pulse operation of up to 155MHz.
Features
Peak value controlled triple laser switch.
Operation from CW up to 155MHz.
Spike-free switching.
Laser current of 100mA per channel from 3.5 to 5V supply voltage.
Single-failure proof with second monitor diode.
System-enable with self test.
Seperate setting of laser power via external resistors.
Strong suppression of transients with very small external capacitors.
Adjustable laser current limitation.
All current LD types can be used (M/N/P).
Error signal output at shutdown and current limitation.
Datasheets
Manufacturer: iCHaus GmbH
Description
Applications
Laser light barriers
Distance measurement
Bar-code readers
Laser projection
Packages
QFN28
Additional information
| LD Pinout | M, N |
|---|---|
| Type | Laser Driver |
| Control Type | APC |
| Laser Speed | CW, Pulsed |
| Supply Current | mA |
