iC-WG
14-Bit Differential Scanning Opto Encoder senses absolute for high resolutions.
Features
Operates from a single 4.5 to 20V supply.
Excellent matching, high reliability.
Differential scanning eliminates dark current effects (half-track width: 300µm).
Comparators with precise photocurrent related hysteresis.
Short-circuit-proof CMOS- ⁄ LSTTL-compatible outputs.
Adjustable LED-current control for constant photosensor currents.
Control monitoring with alarm output.
Operates from 4.5 to 20V supply voltage.
Options: extended temperature range of -30 to 110°C, customised COB, reticle assembly and code disc available.
Datasheets
Manufacturer: iCHaus GmbH
Description
Applications
Optical position decoding with 14 bits based on the principle of differential scanning
Packages
BLCC28
Additional information
| Type | Encoder – Optical |
|---|
