Switched-Mode 3.3V and 5V (200mA) Regulator operates from 8 to 36V iC-WDC
Switched-Mode 3.3V and 5V (200mA) Regulator operates from 8 to 36V.
Input voltage 8 to 36Vdc.
Highly efficient down converter.
Switching transistor and free-wheeling diode integrated.
Adjustment of the regulator cut-off current with external resistor.
Integrated 100 kHz oscillator without external components.
Switching frequency above the audible range.
Two downstream linear regulators with 200mA⁄25mA output current.
Internal reference voltages.
Small residual ripple with low capacitances in the µF range.
Fault message at overtemperature and undervoltage at current-limited open-collector output.
Shutdown of switching regulator at overtemperature.
Low space requirement.
Option: enhanced temperature range of -40 to 85°C.
Manufacturer: iCHaus GmbH
