Linear Anisotropic MagnetoResistance (AMR) Sensor for 2mm pitch
iC-SM2L
Linear Anisotropic MagnetoResistance (AMR) Sensor for 2mm pitch.
Features
Magneto resistive position sensor based on the AMR effect.
Strong field sensor for 2mm N⁄S pole pitch.
One sine⁄cosine cycle per pole width (averaged using a pair of N⁄S poles).
High interpolation due to a sine signal with few harmonics.
Low saturation field strength.
High amplitude consistency with changes in distance.
Resistant to strong magnetic fields.
Not sensitive to external homogeneous magnetic fields.
Datasheets
Manufacturer: iCHaus GmbH
Additional Information
| Type | Sensors – Magnetic |
|---|
