BiSS Interface Master, 1-Chan./3-Slaves (new)


BiSS Interface Master, 1-Chan./3-Slaves.


Bidirectional BiSS sensor communication with up to 3 slaves.
Synchronous sensor data acquisition with cyclic transfer at data rates of up to 10 MHz.
Data lengths of up to 64 bits for sensor data, independently scalable for each slave.
Automatic compensation of line delays, measurement and conversion times.
Data verification by CRC polynomials of up to 8 bits, adjustable per slave and data area.
32 bytes of intermediate memory to ease bidirectional slave register communications.
Supports SSI protocol for unidirectional communication.
Slave register operations during cyclic data transfers.
Separate memory banks enable free controller access during BiSS sensor data transfers.
Parallel controller interface with an 8 bit data / address bus services Intel and Motorola devices with combined data and adress bus.
Serial controller communication by SPI™-compatible mode.
Single 3 to 5V supply, industrial temperature range.


Manufacturer: iCHaus GmbH
SKU: BiSS Interface Master, 1-Chan./3-Slaves (new) Category: Tags: , ,

Product Description


Bi-directional communication in multi-sensor systems
Linear and rotary encoders
Motor-feedback systems


TSSOP24 Package
QFN28 Package


Additional Information


I/O Circuits – BiSS
