SP-6208

Description

The SP-6208 is a high performance widescreen panel mount panel PC with multi-processing support due to the Intel Core-i series CPU and is designed to be lowered into the front of a cabinet. The built-in 18.5″ LCD panel provides 1366 x 768 (WXGA) resolution, and the projected capacitive touch sensor provides precise control.
The dual Gigabit LAN, USB3.0 and four COM ports are among the many I/O ports available, along with optional 802.11g/n wireless, and PCI-e or PCI slot expansion.

Features

18.5″ Widescreen Panel PC
Supports Dual/Quad Core CPU
Dual 1000Mbps LAN
Projected Capacitive touch screen
Support up to 32GB of RAM
Optional 100mm VESA mount
IP65 Stainless Steel bezel

Suitable for:

Factory Control
Industrial Automation

Downloads:

SKU: 18.5" Intel Core-i HMI Terminal (Panel Mount) Categories: , Tags: , , ,

Description

CPU Type
Intel Core i3/i5/i7 (rPGA-988 Embedded) with QM77 or HM76 chipset
Memory Support
2pcs x DDR-3 SO-DIMM socket (up to 32GB)
Front Bezel
Aluminium
Waterproof Level
IP65 front side
Power Supply
9-36V DC input, optional AC-DC power supply
O/S Support
Win XP / 7 / 8
Dimension
486 x 318.5 x 123.5mm
Basic System Weight
10.2Kg
VESA support
100mm VESA bracket (optional)
Certificate
CE / FCC

I/O Ports

Drive Bays
1 x 2.5″ SATA HDD, 1 x CFast slot onboard
USB
4 x USB 3.0
Serial Ports
4 x 9-pin*, COM2 for RS232/422/485
Parallel
1 x 25-pin, supporting SPP, EPP and ECP
Keyboard/Mouse
n/a
LAN
2 x 10/100/1000Mbps
Wireless LAN
Optional 802.11b/g/n card (mini-PCI-e)
Audio
Line-out, MIC
Expansion
1 x PCI-e x4 or 1 x PCI
VGA
1 x 15-pin VGA
Digital I/O
8 in / 8 out
LCD
18.5″ WXGA TFT LCD
Touch Screen
Projected Capacitive (USB interface)

Environment

Temperature
Operating: -5 to 45°C, Storage: -20 to 80°C
Humidity
10 to 90%

Additional information

Screen Size

18.5", 19"

Core

Intel, Intel Core i3, Intel Core i5, Intel Core i7

Fanless

Yes

Expansion

CFast, mini PCI-e, PCI-e, SIM Card

Mount Type

Panel Mount, VESA Mount

Operating System (OS)

Windows 7, Windows XP

Operating Temperature

-5°C to 45°C

IP Rating

IP65 Front Side (Only)
