Product Description
|
CPU Type
|
AMD G-Series T16R (615MHz) or T52R (1.5GHz) embedded type
|
|
Chipset
|
AMD A55E
|
|
Memory Support
|
1pcs x DDR-3 SO-DIMM socket (up to 4GB)
|
|
Power Supply
|
Support ATX and AT power
|
|
Power Requirement
|
+5V and +12V
|
|
BIOS
|
AMI BIOS
|
|
Watchdog Timer
|
1-255 seconds selectable with reset and NMI
|
|
Dimension
|
185 x 122 mm (7.28in x 4.8in)
|
I/O Ports
|
SATA
|
2 x SATA2.0
|
|
FDD
|
1 x 34-pin header on board
|
|
USB
|
2 x USB 2.0
|
|
Expansion BUS
|
1 x PC104
|
|
Optional Storage
|
1 x CFast card
|
|
Parallel Port
|
1 x 25-pin, supporting SPP, EPP and ECP
|
|
Serial Ports
|
2 x 9-pin, COM2 for RS232/422/485
|
|
IrDA
|
1 x SIR
|
|
Keyboard/Mouse
|
1 x mini-DIN
|
|
LAN
|
Realtek Gigabit
|
|
Audio
|
Realtek ALC888S
|
|
LCD Interface
|
18 or 24-bit LVDS
|
Environment
|
Temperature
|
Operating: 0 to 60°C, Storage: -40 to 85°C
|
|
Humidity
|
20 to 90%
|
