BH-0927
Click to enlarge
BH-0927 bh-0927-back

Intel Core-i Half-Size ISA Motherboard

BH-0927

Description

The BH-0927 is a low power PICMG1.3 half-size single board computer built around the Intel i3/i5 CPU.
The eight USB ports and two COM ports are among the many I/O ports available on this single board computer, along with SATA and CFast card support.

Features

Intel i3/i5 Half Size Industrial CPU card
Support Core i3/i5 (embedded)
Dual Gigabit LAN
Support ATX and AT power supply
Support 2 x SATA-III
Support up to 16GB of RAM
CFast card expansion
Digital I/O port

Downloads:

SKU: Intel Core-i Half-Size ISA Motherboard Category: Tags: ,

Product Description

CPU Type
Intel Core i3 / i5 embedded type (1.8 – 2.7GHz)
Chipset
Intel HM86
Memory Support
2pcs x DDR-3L SO-DIMM socket (up to 16GB)
Power Supply
Support ATX and AT power
Power Requirement
+5V, +12V, +3.3V, +5Vsb
Power Consumption
TBD
Watchdog Timer
1-255 seconds selectable
Dimension
198 x 126 mm

I/O Ports

SATA
2 x SATAIII connector
USB
2 x USB 2.0 (backplane), 2 x USB 3.0 (internal), 4 x USB 2.0 (internal)
Optional Storage
1 x CFast card (up to 32GB)
Parallel Port
n/a
Serial Ports
2 x header, COM2 for RS232/422/485
IrDA
n/a
Keyboard/Mouse
n/a
LAN
2 x 10/100/1000Mbps Intel (I217LM + I211AT)
Audio
Optional HD Audio Daughter board
Graphics
1 x VGA, 1 x Display Port (GFX chip built into CPU)

Environment

Temperature
Operating: 0 to 60°C, Storage: -40 to 85°C
Humidity
20 to 90%

Additional Information

Core

Intel, Intel Core i3, Intel Core i5

Board Size

Half Size Card

Expansion

CFast, PCI-e

Fanless

No
