Product Description
|
CPU Type
|
Intel Atom N2600 (1.6GHz)
|
|
Memory Support
|
1pcs x DDR-3 SO-DIMM socket (up to 4GB)
|
|
Bezel
|
Stainless Steel
|
|
Waterproof Level
|
IP65 6-side
|
|
Power Supply
|
DC 12~36V direct, or External AC 90~264V PSU
|
|
O/S Support
|
Win 7 or 7e
|
|
Dimension
|
347 x 286 x 86mm
|
|
Basic System Weight
|
7kg
|
|
VESA support
|
75mm / 100mm VESA bracket (optional)
|
|
Certificate
|
CE / FCC / IEC-60945 / MIL-STD-810F
|
I/O Ports
|
Drive Bays
|
1 x 2.5″ HDD (160GB), 1 x CF Type II (optional)
|
|
USB
|
4 x USB 2.0 (x6 if without full IP65 rating)
|
|
Serial Ports
|
2 x 9-pin (x6 if without full IP65 rating)
|
|
Parallel
|
n/a
|
|
Keyboard/Mouse
|
n/a
|
|
LAN
|
1 x 10/100/1000Mbps
|
LCD / Touch
|
LCD
|
12″ SVGA TFT LCD (XGA option)
|
|
Brightness
|
300cd/m2 (Optional 1000cd/m2)
|
|
Touch Screen
|
Option: 5 wire analogue resistive (USB interface)
|
|
Options
|
Optical Bonding, Transflective LCD
|
Environment
|
Temperature
|
Operating: 0 to 50°C, Storage: -30 to 70°C
|
|
Optional Heater
|
n/a
|
|
Humidity
|
20 to 90%
|
