LCM-84(T)-RSS-IP
Click to enlarge

8.4" SVGA Fully IP65 Monitor with optional BNC

LCM-84(T)-RSS-IP

Description

The LCM-84(T)-RSS-IP is an 8.4″ fully IP65 rated waterproof LCD monitor designed for industrial automation and monitoring in harsh environments. The 8.4″ LCD panel provides 800 x 600 (SVGA) resolution.
With the option of touch screen and VESA mount, the monitor can also be used as an interactive terminal.

Features

8.4″ IP65 Waterproof Monitor
800 x 600 Resolution
VGA and optional DVI or BNC input
VESA mount
Fully IP65 (NEMA4) rated
Optional sunlight readable LCD
Optional optical bonding
Support AC or DC 12V input
Stainless Steel Bezel

Suitable for:

Food Processing Plant, Abattoir
Submarines, Ships & Yachts
SKU: 8.4" SVGA Fully IP65 Monitor with optional BNC Categories: , , Tags: , , , , ,

Product Description

Screen Size
8.4″, 800 x 600 resolution
Display Colours
16.7M
Pixel Pitch
TBD
Luminance
Typ. 300cd/m2 (1000cd/m2 optional)
Viewing Angle
Horizontal: Typ. 70°/70°, Vertical: Typ. 60°/60°
Contrast Ratio
Typ. 350:1
Mount Type
VESA-75 arm mount
Power Input
DC 12V
Dimension
280 x 225 x 54mm
Weight
5Kg
Chassis
Stainless Steel

I/O Ports

Analogue
VGA
Optional
DVI + BNC

Front Glass Options

Touch Sensor Type
Optional 5 wire resistive (USB or serial)
Other Options
Vandal Proof, toughened glass, Optical Bonding

Environment

Operating Temperature
-10 to 60°C
Storage Temperature
-20 to 80°C

Additional Information

Waterproof

Yes
IP Rating

Fully IP65
Mount Type

VESA Arm Mount
Operating Temperature

-10⁰C to +60⁰C
Inputs

BNC, DVI, VGA
Touch Type

Resistive
Screen Size

8.4″
Monitor Type

Waterproof/Outdoor
