iC-LK

Light-Grid Pulse Receiver with Integrated Photodiode.

Features

Photoelectric amplifier with integrated photodiode.
Built-in bandpass filter with switchable centre frequency.
Differential current output with open-drain low-side drivers.
Nonlinear transfer function results in wide dynamic range for pulsed photocurrents.
Fast flash recovery time of max. 30µs.
Recovery time below 10µs even for excessive photocurrents within the input range.
Single 5V supply.
Low standby current; circuit activation by input data.
ESD protection.
Function compatible to iC-NE (SEL = hi).

Datasheets


Manufacturer: iCHaus GmbH

SKU: Light-Grid Pulse Receiver with Integrated Photodiode Category: Tag:

Description

Applications

Light curtains
Light barriers
Electro-sensitive protective equipment (ESPE)

Packages

cQFN16
cQFN16 Package

Additional information

Type

Safety Light Curtain – Receiver
